Drone Payloads

UAV Camera​

NIGHTHAWK 2

The NightHawk2 is an EO/IR stabilized camera with a mere weight of 250 grams [8.8 oz]. The NightHawk2 delivers powerful thermal observation alongside long range visible imagery for drone.

  • Zoom : x20 + x2 digital (total x40)
  • HFOV : 60° WFOV – 3° WFOV – 1.5° DFOV
  • Thermal Resolution : 640×480
  • Pitch FOR: -45° to +135°
  • Roll FOR: -180° to +180°
  • Weight : 250 grams [8.8 oz.]
  • Dimensions : Diameter=66mm [2.6”] x Height=94 mm [3.7”]
drone payload for military UAV

NIGHTHAWK

The NightHawk is an EO/IR stabilized camera with a mere weight of 220 grams [7.8 oz]. The NightHawk delivers powerful thermal observation alongside visible imagery for UAV.

  • Visible Zoom : x6.6 + x2 digital (total x13.2)
  • HFOV : 31° WFOV – 4.7° WFOV – 2.3° DFOV
  • Thermal Resolution : 640×480
  • Pitch FOR: -45° to +135°
  • Roll FOR: -180° to +180°
  • Weight : 220 grams [7.8 oz.]
  • Dimensions : Diameter=66mm [2.6”] x Height=94 mm [3.7”]
drone camera

COLIBRI 2

The Colibri2 is a dual EO-IR stabilized camera built for professionals drons needing a quality camera for day and night use. Weighing in at 180 grams [6.3 oz], the Colibri2 offers excellent image quality and sharpness to capture detailed imagery, such as license plates and faces.

  • Zoom : x20 + x2 digital (total x40)
  • FOV : 60° WFOV – 3° WFOV – 1.5° DFOV
  • Thermal Resolution : 640×480
  • Pitch FOR: -45° to +90°
  • Roll FOR: -180° to +180°
  • Weight : 180 grams [6.3 oz.]
  • Dimensions : 53mm [2.099”] x Height=78mm [3.07”]
drone camera fot military drone

COLIBRI

The Colibri is dual-channel EO/IR stabilized camera with a minimal weight of 160 grams [5.6 oz]. The Camera provides unparalleled capabilities in its weight category, providing an excellent choice for those in need of a light and powerful camera for the drone activity.

  • Zoom : x6.6 + x2 digital (total x13.2)
  • HFOV : 31° WFOV – 4.7° NFOV – 2.3° DFOV
  • Thermal Resolution : 640×480 or 384×288
  • Pitch FOR: -45° to +135°
  • Roll FOR: -180° to +180°
  • Weight : 160 grams [5.7 oz.]
  • Dimensions : Diameter=53mm [2.099”] x Height=78mm [3.07”]
uav camera for military drone

DRAGONEYE2

DragonEye2 is a dual EO-IR stabilized camera with a mere weight of 115 grams offering unparalleled long range observation capability.

  • Zoom : x20 + x2 digital (total x40)
  • HFOV : 60° WFOV – 3° NFOV – 1.5° DFOV
  • Thermal Resolution : 640 x 480
  • Pitch FOR: -45° to +135°
  • Roll FOR: -180° to +180°
  • Weight : 115 grams
  • Dimensions : 40 mm x 40 mm x 65mm

CHIMERA

Chimera payload use state-of-the-art object recognition analytics on a high-end day and night system incorporating an uncooled LWIR thermal imager and HD day EO camera in a compact lightweight package.

  • Zoom : X7 optical X2 digital
  • Thermal Resolution : 640X480
  • Pitch FOR: 0°-135°
  • Roll FOR:  ±45°
  • Yaw FOR: ±360°
  • Weight : 360 grams
  • Dimensions : 7X6X4.5 cm

MARS

Dual-channel EO/IR 2 axis stabilized camera with a weight of 350 grams .

  • Zoom : x10+ x2 digital (total x20)
  • HFOV : 62° – 5°
  • Thermal Resolution : 640×480
  • Pitch FOR: -45° to +135°
  • Roll FOR: -100° to +100°
  • Weight : 350 grams.
  • Dimensions : 100mm x100mm, Height=100mm
uav camera

JUPITER

Cost effective day-channel EO, 2 axis stabilized camera with a weight of 350 grams .

  • Zoom : x10+ x2 digital (total x20)
  • HFOV : 54° – 5°
  • Pitch FOR: -45° to +135°
  • Roll FOR: -100° to +100°
  • Weight : 350 grams.
  • Dimensions : 100mm x100mm, Height=100mm
uav payload
